Référence | Désignation | Prix Unitaire TTC | Qté | |||
---|---|---|---|---|---|---|
# 1 |
11511-11400-000 1151111400000 1151111400000 |
OIL PAN
PAN, OIL |
Non disponible | |||
# 2 |
11489-11400-000 1148911400000 |
JOINT DE CARTER D'HUILE
GASKET |
Non disponible | |||
# 3 |
01517-06255-000 01550-0625B-0000151706255000 |
BOLT
BOLT (6X25) |
||||
# 3 |
01517-06258-000 01550-0625A-0000151706258000 |
BOLT
BOLT (6*25) |
||||
# 4 |
01517-06205-000 01550-0620B-0000151706205000 |
BOLT
BOLT, EXTENSION |
||||
# 4 |
01517-06208-000 01550-06207-0000151706208000 |
VIS 6X20MM, 6-PANS
BOLT (6X20) |
||||
# 5 |
09247-14001-000 09247-14002-0000924714001000 |
PLUG
BOLT |
||||
# 6 |
09168-14004-000 0916814004000 0916814004000 |
BAGUE DE JOINT 14.1X18X1.5MM
WASHER ![]() |
||||
# 7 |
16440-33300-000 16440-11D00-0001644033300000 |
REGULATEUR D'HUILE
REGULATOR, OIL |
||||
# 8 |
08212-14181-000 0821214181000 0821214181000 |
BAGUE DE JOINT
WASHER |
||||
# 9 |
16510-45040-000 1651045040000 1651045040000 |
FILTRE D'HUILE
FILTER ENGINE OIL |
Non disponible | |||
# 10 |
16518-45000-000 1651845000000 1651845000000 |
JOINT TORIQUE
O RING |
Non disponible | |||
# 11 |
09440-32004-000 0944032004000 0944032004000 |
RESSORT
SPRING |
||||
# 12 |
16512-45101-000 1651245101000 1651245101000 |
COUVERCLE FILTRE A HUILE
COUVERCLE |
Non disponible | |||
# 13 |
16512-44410-000 16512-45D00-0001651244410000 |
COUVERCLE
CAP, ENGINE OIL FILTER |
||||
# 14 |
01421-06208-000 01421-0620A-0000142106208000 |
BOLT, STUD
|
||||
# 15 |
08313-11065-000 0831311065000 0831311065000 |
NUT
NUT, CENTER |
Non disponible | |||
# 15 |
08313-11068-000 0831311068000 |
ECROU 6MM
NUT |
Non disponible | |||
# 16 |
08322-21065-000 0832221065000 |
WASHER
|
Non disponible | |||
# 17 |
16520-11400-000 1652011400000 1652011400000 |
CRIBLE D'HUILE
STRAINER, ENGINE OIL |
Non disponible | |||
# 18 |
02112-06128-000 02112-06127-0000211206128000 |
VIS 6X12MM
.6 X 12 CROSS SCREW |
||||
# 19 |
16400-44100-000 1640044100000 1640044100000 |
POMPE A HUILE COMPLET
PUMP, ENGINE OIL |
||||
# 20 |
09280-13004-000 0928013004000 0928013004000 |
JOINT TORIQUE D: 1.9, ID: 13
O RING ![]() |
||||
# 21 |
02112-06258-000 02112-0625A-0000211206258000 |
SCREW
SCREW (6*25) |
||||
# 22 |
16331-11400-000 1633111400000 1633111400000 |
PIGNON ENTRAINEMENT DU POMPE
GEAR, DRIVEN (NT:25) |
Non disponible | |||
# 23 |
08221-10185-000 0822110185000 0822110185000 |
RONDELLE
WASHER |
||||
# 24 |
09261-04009-000 0926104009000 0926104009000 |
BOULON 4X15.8
PIN 16X10 ![]() |
||||
# 25 |
08331-31109-000 0833131109000 0833131109000 |
CIRCLIP, 10MM
CIRCLIP ![]() |
